Molybdenum heating element for sapphire growth furnace

Molybdenum heating element for sapphire growth furnace

Molybdenum heating element – Molybdenum rod

1. Performance:

• Pureness: Mo≥99.95%;
• Density: ≥10.2g/cm3;
• Temperature of the working environment: ≤2200℃.

2. Dimension: (mm)

Diameter	Width	Height	The shape of the bottom and the bending radius
3	≤650	≤1200	According to customer requirements
4	≤600	≤1150
5	≤550	≤1100
6	≤550	≤1050
7	≤500	≤1000
8	≤500	≤950
9	≤450	≤900

Molybdenum for Sapphire Growth Furnace(2)

Molybdenum for Sapphire Growth Furnace

Molybdenum Mandrel

Density≥9.6g/cm³, the Vickers hardness up to 350 or more;

For making stainless steel, alloy steel and high-temperature alloy seamless tubes;

Blank molybdenum mandrel & finishing molybdenum mandrel.

Molybdenum Seed Chunk for Sapphire Crystal Growth Furnace, 99.95% Mo

Tungsten and Molybdenum for Sapphire Growth Furnace(3)

W and Mo for Sapphire Growth Furnace

 Tungsten & Molybdenum bracket for sapphire furnace

Tungsten & Molybdenum heater for sapphire crystal furnace



Tungsten & Molybdenum electrode screen for crystal growth furnace

Thermal Field for Sapphire Growth Furnace

Thermal Field for Sapphire Growth Furnace

As the components for heat insulation of sapphire growth furnace, thermal field play a key role in insulating and reflecting the heat in the furnace. With high purity, size precision, smooth surface, easy assembly, reasonable design, the component for heat insulation plays an important role in improving the quality of the sapphire crystal.

Performance:

1、Pureness: Mo≥99.95% or W≥99.95%;

2、Density: Mo ≥10.1g/cm3 or W ≥19.1g/cm3;

3、Temperature of the working environment: ≤2400℃.

Tungsten and Molybdenum for Sapphire Growth Furnace(2)

Tungsten and Molybdenum for Sapphire Growth Furnace

Heat Shield

The Components for heat insulation of Sapphire Crystal Furnace, prevent heat loss and protect the uniformity of the temperature of the thermal field.

Data

Name	Material	Content	Density
Molybdenum plate	Mo(Molybdenum)	≥99.95%	≥10.0 g/cm3
Tungsten plate	W(Tungsten)	≥99.95%	≥19.0 g/cm3

Dimension

O.D. (mm)		H. (mm)		Layer(times)
min	max	min	max	min	max
300	1000	300	1500	2	30

Molybdenum for Sapphire Growth Furnace

Molybdenum for Sapphire Growth Furnace

Molybdenum Barrel Screen, one kind of molybdenum heat shield, but riveted into the barrel shape.

Molybdenum boat

Material: pure Molybdenum and TZM alloy

Dimensions: (20mm-100mm) x (20mm-100mm) x (50mm-800mm) length; thickness (0.5mm-5.0mm)

Performance: high temperature resistant, not easily deformed, has long service life

Tungsten and Molybdenum for Sapphire Growth Furnace

Tungsten and Molybdenum for Sapphire Growth Furnace

Spiral mesh tungsten heater can improve the uniformity of the temperature zone. It has the property of long service life and is difficult to be damaged.



As the components for heat insulation of sapphire growth furnace, molybdenum reflective shield and the upper and lower cover plate play a key role in insulating and reflecting the heat in the furnace. With high purity, size precision, smooth surface, easy assembly, reasonable design, the component for heat insulation plays an important role in improving the quality of the sapphire crystal.

Tungsten for Sapphire Growth Furnace

Tungsten for Sapphire Growth Furnace

Since the melting point of the tungsten is up to 3410℃, the tungsten crucible is widely used in the sapphire single crystal growth furnace, quartz glass melting furnace, rare earth smelting furnace and other core container in industrial furnace. In general, the temperature of the working environment of tungsten crucibles is over 2000℃.

With the property of high purity, high density, well-made and reasonable design, tungsten heater components are of great importance in the quality control, energy conservation, and service life of sapphire crystal.
